Get Ready for Kafka 4: Changes and Upgrade Considerations

Apache Kafka 4, the much-anticipated next major release of the popular event streaming platform, is almost here. In this blog, find out what's changing in 4.0 and how to plan your next Kafka upgrade.

Apache Kafka Project Update

With four minor releases (3.6 through 3.9), several patches, and a major release on the horizon, 2024 has arguably been the most eventful in the history of the Apache Kafka project. The biggest development, of course, is the upcoming release of Kafka 4, which we will discuss more in depth later in this blog. First, let's review the 3.x releases from this year that contained significant updates related to some of the key changes coming in 4.0.

Most of the 3.x updates have been made with the upcoming 4.0 Zookeeper deprecation in mind. ZooKeeper has been replaced by Kafka Raft (KRaft) mode and an official Zookeeper to KRaft migration process was introduced in 3.6 and designated as production ready in 3.7. Prior to 3.6, the only way to move to a KRaft-based Kafka cluster was a complete “lift and shift” process, which entailed installing a new KRaft-based cluster and then manually moving topics, producers, and consumers.

JBOD (Just a Bunch of Disks) support for migrating KRaft clusters also was added in 3.7, and some existing features got enhancements as well, such as improved client metrics and observability as defined in KIP-714 and early access to the next-gen consumer rebalancing protocol defined in KIP-848. Java 11 was also marked for deprecation in 3.7 and will be no longer be supported in 4.0.

With 3.8 and 3.9, Log4j appender was deprecated (and also targeted for removal in 4.0) and KIP-848 was promoted to preview status. There were also several improvements made to KRaft migration, and the quorum protocol implemented in KRaft. Support for dynamic KRaft quorums (as detailed in KIP-853) makes adding or removing controller nodes without downtime a much simpler process. With these improvements, Kafka 3.9 has basically become the de facto “bridge release” to 4.0.

Kafka 4 Release Date

According to the Kafka 4.0 release plan, feature freeze concluded on December 11th, 2024 and there is a planned code freeze on January 15th, 2025. This means Kafka 4 will likely come out in the final days of January or early February, as the code freeze is typically followed by a stabilization period lasting at least two weeks.

What's Changing in Kafka 4

Based on the latter 3.x releases described above, we know that the biggest changes in Kafka 4 are removals, all noteworthy, though some more monumental than others.

Kafka Raft Mode (KRaft) Replaces ZooKeeper

The most notable change in Kafka 4 is that you can no longer run Kafka with ZooKeeper, with KRaft becoming the sole implementation for cluster management. While KRaft mode was marked as production ready for new clusters in 3.3, a few key pieces were needed before ZooKeeper deprecation and removal could be implemented. With the introduction and refinement of the migration process and JBOD support, the Kafka development community feels that total removal of ZooKeeper is finally ready with 4.0.

MirrorMaker 1 Removed

While not as huge of an architectural shift as the ZooKeeper removal, MirrorMaker 1 support is also going away in 4.0. Given that most organizations dropped  MirrorMaker 1 for MirrorMaker 2 quite some time ago, we expect this change to be less impactful to the Kafka ecosystem, but it is still notable nonetheless.

Kafka Components Logging Moving to Log4j2

With Log4j marked for deprecation in 3.8, 4.0 will also mark the complete transition from Log4j to Log4j2. After the Log4Shell vulnerability was disclosed in late 2021, an industry-wide effort to move to Log4j2 was put into motion. For this reason, most organizations already have moved off of Log4j, so while still a noteworthy change, it should not be all that impactful (and if you are still using Log4j, your systems are already most likely pwned at this point!).

Want More Kafka Insights?

Download the Decision Maker's Guide to Apache Kafka for tips on partition strategy, using Kafka with Spark, security best practices, and more.

Read Guide

Kafka 4 Migration and Upgrade Considerations

There are definitely some considerations that should be taken into account when planning your 4.0 upgrade. First, if this is your first foray into KRaft, don’t plan on retiring your entire ZooKeeper infrastructure anytime soon. Best practices dictate that organizations should be running dedicated controller nodes for production clusters, so your production infrastructure will most likely not change. For dev and integration/testing environments, running in mix-mode is fine, so you might see some infrastructure reclamation occurring in those environments.

Another major consideration is the upgrade path you will need to take. Since ZooKeeper is gone in 4.0, there will be no migration functionality associated with 4.0. So, for organizations still running Zookeeper on a Kafka version prior to 3.7, an interim upgrade to 3.9 would be required. Technically, with migration improvements introduced with 3.9, I’d recommend doing this interim step even for installations later than 3.7. The upgrade path would look something like:

3.x => 3.9 => ZK to KR migration => 4.0

Also of note is that Kafka 3.5 and later use a version of ZooKeeper that is not wire-compatible with version 2.4 and older. As such, for older Kafka clusters, a couple of additional interim steps will be required as well. You would need to upgrade to Kafka 3.4, and then upgrade the version of ZooKeeper to 3.8. That migration path might look something like this:

2.3 => 3.4 => ZK 3.8 => 3.9 => ZK to KR migration => 4.0

This should be an edge case since older versions prior to 2.4 should mostly be retired at this point.

What to Expect in Future Kafka 4.x Releases

If past precedence is any indication of future plans, I believe we will see continued improvements for containerization support and metrics collection, as well as refinements in the KRaft migration process. In regards to consumer performance, the full release of KIP-848 will also bring significant changes. Moving the complexity of the rebalancing protocol away from clients into the Group Coordinator, with a more modern event-loop process, creates a more incremental approach to rebalancing, where group-wide synchronization events will no longer be required for all coordination events.

Regardless, the future of Kafka looks pretty bright, with these enhancements likely to make the already popular event-streaming platform even better and more efficient.
